Protective: The surge protector can effectively protect your devices from electrical hazards, voltages, and other potential damage caused by overheating.
Nice quality: The surge protector is made of high-quality abs material, which has good heat dissipation performance and can be used for a long time.
Easy to install: The surge protector is easy to install, just peel off the protective film on the back of the device and stick it on the wall.
Model | SPD2 | |
Standard | IEC EN50539-11; GB18802.11 | |
Protection Grade | T2, Class II | |
Max Continuous Working Voltage Uc | AC275V/AC385V | |
Nominal Discharge Current In 8/20μs | 20KA | 30KA |
Max Discharge Current In 8/20μs | 40KA | 60KA |
Lightning Impulse Current 10/350μs | 12.5KA | |
Voltage Protection Level Up | 2.2KV-4KV | |
Number of Poles | 2P / 3P / 4P | |
Response Time Ta | ≤25ns | |
Connecting Cable | ≥4mm², Ground Wire ≥6mm² | |
Method of Installation | 35mm DIN Rail | |
Matched Fuse or Circuit Breaker | ≥32A | |
Operating Temperature Range | -40°C ~ +80°C | |
Housing Color Module/Base | Grey/White | |
Protection Class | IP20 | |
Tightening Torque | 3.0N.m | |
Terminal Connection Type | Phillips Screws | |
Certificate | CE, ISO9001-2015 | |
Working Status Indicator Window | Green (working well), Red (malfunction, product or module must be replaced) |
